Sonnet Raw Dawg III
Sonnet RawDawg III
2021 marked 10 years of collaboration between grammy nominated artist Eric GALES and MAGNETO® Guitars. The 2022 released "Crown" album produced by Joe BONAMASSA has hit record sales in the Blues album cathegory.
MAGNETO® guitars has produced several custom versions of the Eric GALES “RawDawg” guitar in the past years, we have always worked on the same type of body and neck combinations but we have tried to add a new feature at every new rendition making it a high grade instrument with a solid price tag.
In early 2020, we started to talk about the idea of producing a new Signature guitar that would be made available to a broader audience. We kept on talking with Eric and tried many options and we have also developed specific parts for that guitar. An important part of the plan was to develop a specific range of single coil pickups that would have the dynamics and great midrange response which play an important role in Eric’s guitar tone.
The MAGNETO Eric GALES RD3 will feature a basswood body as well as a roasted maple neck with a rosewood fingerboard. The new signature model is available in Sunset Gold finish and will sport a Gold mirror pickguard and backplate, a Gotoh tremolo, Gotoh tuners as well as the new Magneto Metro-Poles EG1 pickups.
www.magnetoguitars.com
www.ericgales.com
COLOR OPTIONS
Click color names for guitar pictures
SPECIFICATIONS
BODY | |
Body Wood: | Basswood, 2-Piece |
Finish: | Polyurethane Finish |
Pickguard: | Gold Mirror |
NECK | |
Neck Wood: | Hard Rock Maple / Roasted |
Headstock: | Eric Gales Signature |
Finish: | Satin Urethane |
Fingerboard: | East Indian Rosewood with Inlayed Eric Gales Signature |
Scale length: | 648mm / 25 ½” |
Nut Material: | Bone |
Nut Width: | 42 mm / 1.650” |
Frets: | .096” X .047” Narrow Jumbo Style Frets (6105 Style) |
Nr.of Frets: | 22 frets |
Neck Profile: | Medium C Shape |
Radius: | 12” / 305mm Radius |
Neck Heel: | Tapered |
Truss Rod: | Double Truss Rod |
Truss Rod Nut: | Setting at headstock with Allen key |
HARDWARE | |
Bridge: | Gold Gotoh” Custom Vintage Style Tremolo with Steel Plate Saddles and Steel Block, 56mm pitch |
Tuners: | SG-360-07, Gear Ratio 14:1, Made by Gotoh |
String Retainer: | Vintage Style, made by Gotoh |
Neckplate: | Custom engraved "RawDawg" Neckplate |
Hardware Finish: | Gold |
ELECTRONIC PARTS | |
Pickups: | Magneto Metro-Poles Custom EG1 Set |
Pickup Switch: | Standard Position Switch |
Switching: | Standard 5-way |
Controls: | Master Volume, Master Tone |
Pots: | Audio Taper Pots |
Output Jack: | Mono Jack |
STRINGS: | 010-046 Standard Tuning |
Bag: | Magneto Bag included |
ACCESSORIES: | Tremolo Arm |
Allen Wrench for Bridge Adjustments, Allen Key for Neck adjustment |
Sonnet Standard US-1200
Sonnet Standard US-1200
Magneto's version of the classic 3 single coil sound for the budged minded player.
COLOR OPTIONS
Click color names for guitar pictures
SPECIFICATIONS
BODY | |
Body Wood: | Basswood, 2-Piece |
Finish: | Polyurethane |
Pickguard: | Finished Wood |
NECK | |
Neck Wood: | Hard Rock Maple |
Headstock: | Magneto Sonnet Headstock |
Finish: | Satin Polyurethane |
Fingerboard: | Rock Maple |
Scale length: | 648mm / 25 ½” |
Nut Material: | Synthetic Bone |
Nut Width: | 42 mm / 1.650” |
Frets: | .096” X .047” Narrow Jumbo Style Frets by Sanko, Japan |
Nr.of Frets: | 22 frets |
Neck Profile: | Medium C Shape |
Radius: | 12” / 305mm Radius |
Neck Heel: | Tapered |
Truss Rod: | Double Truss Rod |
Truss Rod Nut: | Classic Top Loaded System |
HARDWARE | |
Bridge: | Vintage Style Tremolo |
Tuners: | Magneto Tuners |
String Retainer: | Vintage Style E and B String, G and D String |
Neckplate: | Standard |
Hardware Finish: | Chrome |
ELECTRONIC PARTS | |
Pickups: | USC-200 Singles Coil Pickups |
Pickup Switch: | 5-Position Switch |
Switching: | Standard 5-way |
Controls: | Volume, Tone |
Pots: | Audio Taper Pots |
Output Jack: | Mono Jack |
STRINGS: | 010-046 |
CASE: | Magneto Bag |
ACCESSORIES: | Tremolo Arm |
Allen Wrench for Bridge Adjustments, Neck Adjustment Pin |
Sonnet Classic US-1300
Sonnet Classic US-1300
Magneto guitars are cratfed to hit the stage, no matter your level or style of music.
COLOR OPTIONS
Click color names for guitar pictures
SPECIFICATIONS
BODY | |
Body Wood: | Basswood, 2-Piece |
Finish: | Polyurethane |
Pickguard: | Finished Wood |
NECK | |
Neck Wood: | Hard Rock Maple |
Headstock: | Magneto Sonnet Headstock |
Finish: | Satin Polyurethane |
Fingerboard: | East Indian Rosewood |
Scale length: | 648mm / 25 ½” |
Nut Material: | Synthetic Bone |
Nut Width: | 42 mm / 1.650” |
Frets: | .096” X .047” Narrow Jumbo Style Frets by Sanko, Japan |
Nr.of Frets: | 22 frets |
Neck Profile: | Medium C Shape |
Radius: | 12” / 305mm Radius |
Neck Heel: | Tapered |
Truss Rod: | Double Truss Rod |
Truss Rod Nut: | Classic Top Loaded System |
HARDWARE | |
Bridge: | Vintage Style Tremolo |
Tuners: | Magneto Tuners |
String Retainer: | Vintage Style E and B String, G and D String |
Neckplate: | Standard |
Hardware Finish: | Chrome |
ELECTRONIC PARTS | |
Pickups: | USC-200 Singles, MHN-200 Humbucker |
Pickup Switch: | 5 Position Switch |
Switching: | Standard 5-way |
Controls: | Volume, Tone |
Pots: | Audio Taper Pots |
Output Jack: | Mono Jack |
STRINGS: | 010-046 |
CASE: | Magneto Bag |
ACCESSORIES: | Tremolo Arm |
Allen Wrench for Bridge Adjustments, Neck Adjustment Pin |
UT-Wave Classic UT-2300
UT-Wave Classic UT-2300
COLOR OPTIONS
Click color names for guitar pictures
SPECIFICATIONS
BODY | |
Body Wood: | Basswood, 2-Piece |
Finish: | Polyurethane |
Pickguard: | Finished Wood |
NECK | |
Neck Wood: | Hard Rock Maple |
Headstock: | Magneto UT-Wave Headstock |
Finish: | Satin Polyurethane |
Fingerboard: | East Indian Rosewood |
Scale length: | 648mm / 25 ½” |
Nut Material: | Synthetic Bone |
Nut Width: | 42 mm / 1.650” |
Frets: | Jumbo Style Fret |
Nr.of Frets: | 22 frets |
Neck Profile: | Medium C Shape |
Radius: | 12” / 305mm Radius |
Neck Heel: | Tapered |
Truss Rod: | Double Truss Rod |
Truss Rod Nut: | Classic Top Loaded System |
HARDWARE | |
Bridge: | Fixed Bridge |
Tuners: | Magneto Tuners |
String Retainer: | Vintage Style for E and B String + G and D String |
Neckplate: | Standard |
Hardware Finish: | Chrome |
ELECTRONIC PARTS | |
Pickups: | UTB-200 Bridge PU, UTN-200 Neck PU |
Pickup Switch: | 3-Position Switch |
Switching: | Standard 3-way |
Controls: | Volume, Tone |
Pots: | Audio Taper Pots |
Output Jack: | Mono Jack |
STRINGS: | 010-046 |
CASE: | Magneto Bag |
ACCESSORIES: | Allen Wrench for Bridge Adjustments, Neck Adjustment Pin |
